Name: AC 80x80x38mm
Brand: 科昇科技有限公司

AC 80x80x38mm

Metal blades & Frame
Shaded pole motor
Impedance protected

數量 :

Specifications Specifications are subject to change without notice
Model NO.	VAC	Bearing	HZ	R.P.M	Current(mA)	Watts	CFM	mm-HzO	dB{A)
GWB0381ALB	115	Ball	50/60	1750/2000	120/110	10/9	18.5/21	2.1/2.5	22/26
GW80381ALS	115	Sleeve	50/60	1750/2000	120/110	10/9	18.5/21	2.1/2.5	22/26
GW80382BLB	230	Ball	50/60	1750/2000	75/70	12/11	18.5/21	2.1/2.5	22/26
GW80382BLS	230	Sleeve	50/60	1750/2000	75/50	12/11	18.5/21	2.1/2.5	22/26
GW80381AMB	115	Ball	50/60	2200/2500	130/120	10/9	23/27	3.1/3.6	27/30
GW80381AMS	L115	Sleeve	50/60	2200/2500	130/120	10/9	23/27	3.1/3.6	27/30
GW80382BMB	230	Ball	50/50	2200/2500	85/75	13/12	23/27	3.1/3.6	27/30
GW80382BMS	230	Sleeve	50/60	2200/2500	85/75	13/12	23/27	3.1/3.6	27/30
GWS0381AHB	115	Ball	50/60	2500/2900	130/120	11/10	25/29	3.5/4.6	30/37
GW80381AHS	115	Sleeve	50/60	2500/2900	130/120	11/10	25/29	3.5/4.6	30/37
GW80381AHMB	115	Ball	50/60	2700/3100	140/130	11/10	27/31	3.7/5.2	31/34
GW80381AHMS	115	Sleeve	50/60	2700/3100	140/130	11/10	27/31	3.7/5.2	31/34
GW80382AHMB	200	Ball	50/60	2700/3100	95/85	13/12	27/31	3.7/5.2	31/34
GW30382BHMB	230	Ball	50/60	2700/3100	85/75	13/12	27/31	3.7/5.2	31/34
GW80382BHMS	230	Sleeve	50/60	2700/3100	87/75	13/12	27/31	3.7/5.2	31/34
GW80382CHMB	240	Ball	50/60	2700/3100	85/75	13/12	27/31	3.7/5.2	31/34
GW8038DVHLB	115/230	Ball	50/60	2700/3100	150/80	13/13	27/31	3.7/5.2	31/34
GW8038DVHLS	115/230	Sleeve	50/60	2700/3100	150/80	13/13	27/31	3.7/2.5	31/34
