• AC 172X172X51mm B type

AC 172X172X51mm B type

Blade/Housing
Die-cast aluminum housing
Glass fiber reinforced plastic: impeller are UL94-0 rating
Impedance protected

Specifications Specifications are subject to change without notice
Model NO. VAC Bearing HZ R.P.M Current(mA) Watts CFM mm-H20 dB(A)
GW172511AHL8 115 Ball 50/60 2850/3400 580/550 45/43 185/219 14.5/17 55/60
GW172511AHB 115 Ball 50/60 2800/3200 640/580 48/46 180/215 14.3/16 54/56
GW172512BHLB 230 Ball 50/60 2850/3400 140/160 30/30 185/219 14.5/17 55/60
GW172512BHB 230 Ball 50/60 2800/3200 300/280 46/44 180/215 14.3/16 54/56
GW172513CHB 380 Ball 50/60 2800/3200 300/280 46/44 180/215 14.3/16 54/56
